Thread: Audi A3 8V Auto hold (ABS module) - Anyone figure this out yet?

  1. #21
    Verified VCDS User
    Join Date
    Jun 2014
    Location
    UK
    Posts
    56
    Post Thanks / Like
    It turns out that the CAN installation has to be reset in order to cure this issue. I have another diagnostic tool which did this very easily (VCDS may do it but it wasn't obvious)


    Thankfully normal order has been resumed.
    The question?
    In one of these bytes is Autohold but is also electronic parking brake. Any ideas if I just want to activate autohold without EPB?
    yte 08 = was 00, now 03
    Byte 19 = was 00, now C0
    Byte 23 = was F6, now F7
    Byte 25 = was 42 , now 41
    The above as suggested results in both autohold errors and EPB errors.

  2. Likes ineedbeer liked this post
  3. #22
    Verified VCDS User
    Join Date
    Nov 2014
    Location
    San Josť, Costa Rica
    Posts
    112
    Post Thanks / Like
    Can you clarify if you corrected the DSG errors only, or you managed to also activate auto hold?

  4. Likes ineedbeer liked this post
  5. #23
    Verified VCDS User
    Join Date
    Jun 2014
    Location
    UK
    Posts
    56
    Post Thanks / Like
    At the moment I'm back to normal with no errors.

    I can clairify that if you change byte 25 from 41 to 40 the HHC no longer operates (2 second hold)

    I've calculated the 32 possible HEX combinations of those bytes assuming we only change the bits in your original suggestion and assuming that byte 25 is set to 40.

    Just to try them now and yield the results. It may quite be that you cannot have Autohold without EPB (which Octavias don't have)

    Or that none of the 32 / 64 combinations works

  6. Likes ineedbeer liked this post
  7. #24
    Verified VCDS User
    Join Date
    Oct 2015
    Location
    USA
    Posts
    20
    Post Thanks / Like
    Is there anything I can do to help you guys (my vehicle has EPB and the auto-scan and other pertinent info should be in this thread). I'm just a bit afraid of trying something that could cause near-permanent errors, as I don't have any other tools beyond VCDS with which to try and clear them.

  8. #25
    Verified VCDS User
    Join Date
    Nov 2014
    Location
    San Josť, Costa Rica
    Posts
    112
    Post Thanks / Like
    Quote Originally Posted by ineedbeer View Post
    Is there anything I can do to help you guys (my vehicle has EPB and the auto-scan and other pertinent info should be in this thread). I'm just a bit afraid of trying something that could cause near-permanent errors, as I don't have any other tools beyond VCDS with which to try and clear them.
    I wouldn't try anything. Hold tight, I think we're close.

  9. #26
    Verified VCDS User
    Join Date
    Jun 2014
    Location
    UK
    Posts
    56
    Post Thanks / Like
    Ok, it's not looking good.
    Today I tried the 32 possible combinations of byte 08, Byte 19, Byte 23 with Byte 25 set to 40 at all times.

    Unfortunately 30 of the 32 were "coding rejected".
    The 2 that were successful gave multiple EBP and Autohold errors and the same DSG error (related to EBP)

    I will try the same 32 combinations again tomorrow but with the byte 25 set to 42 not 40 but I'm not hopeful.

    It would seem that the ECU will not accept coding for autohold without EPB.
    Unless anyone has any other ideas?

    Ps VCDS will do the CAN installation reset but it asked for a 3 digit code to do it (nothing listed in any help box) so I had to use my Delphi tool to reset the CAN again after trying (that didn't require any code).

    I'll report back tomorrow :-)

  10. #27
    Verified VCDS User
    Join Date
    Nov 2014
    Location
    San Josť, Costa Rica
    Posts
    112
    Post Thanks / Like
    What car are you trying this on?

  11. #28
    Verified VCDS User
    Join Date
    Jun 2014
    Location
    UK
    Posts
    56
    Post Thanks / Like
    Mine is a 2016 Octavia vRS TSI DSG with ACC and without EPB (it's not even an option on Octavia)

  12. #29
    Verified VCDS User
    Join Date
    Jun 2014
    Location
    UK
    Posts
    56
    Post Thanks / Like
    I have checked my friends Mk7 GTD manual with Autohold and his coding is like this....
    Byte 08 = 07
    Byte 19 = E0
    Byte 23 = F5
    Byte 25 = 60

    I have put out a request on the Mk7 Golf forums for a standard coding string that matched my car more exactly. As you can see they are vastly different to the ones already posted.
    Good fun :-)

  13. #30
    Verified VCDS User lala30's Avatar
    Join Date
    Mar 2015
    Location
    Croatia
    Posts
    83
    Post Thanks / Like
    this is from golf 7 with auto hold and manual

    01FA62A1242509710379060441CB2580462490C06082A4F300 40F076C002

    Byte 08 = 03
    Byte 19 = C0
    Byte 23 = F3
    Byte 25 = 40 (manul)

    this is from R golf 7

    01FA6BA154252973037A070341CB6980D62A94C0E08296F700 420078C208

    Byte 08 = 03
    Byte 19 = C0
    Byte 23 = F7
    Byte 25 = 42 ( Auto Trans)

    audi A3 8V

    with auto hold

    12F162A234260A6D037D070041CA2948462C50C0E08294F5F8 6150788508

    Byte 08 = 03
    Byte 19 = C0
    Byte 23 = F5
    Byte 25 = 61 ( Auto Trans)


    audi A3 8V auto hold

    12F162A224220A70037C060841CB2948462450C0608294F318 6150748608

    Byte 08 = 03
    Byte 19 = C0
    Byte 23 = F3
    Byte 25 = 61 ( Auto Trans)

    audi A3 8V E-tron auto hold

    12F140A238263272037B060541C42948021C4CC0608294F502 A100788608

    Byte 08 = 03
    Byte 19 = C0
    Byte 23 = F5
    Byte 25 = A1 ( Auto Trans)


    Audi A3 8v without auto hold

    13F162A224220A6F0177060541C629C846245080608294F2F4 6150388608

    Byte 08 = 01
    Byte 19 = 80
    Byte 23 = F2
    Byte 25 = 61 ( manual )

    Audi A3 8v without auto hold

    12F16AA224272A730179060341CB2548562454806082A4F202 4200388608

    Byte 08 = 01
    Byte 19 = 80
    Byte 23 = F2
    Byte 25 = 40 ( manual )

    Audi A3 8v without auto hold

    13F162A224260A6D0180060641CA25C8462450806082A4F200 4300788608


    Byte 08 = 01
    Byte 19 = 80
    Byte 23 = F2
    Byte 25 = 43 ( manual ) and activation Hild hold like in skoda octavia 3
    Last edited by lala30; 04-24-2016 at 06:12 AM.
