Thread: Audi A3 8V Auto hold (ABS module) - Anyone figure this out yet?

  1. #1
    Verified VCDS User
    Join Date
    Oct 2015
    Location
    USA
    Posts
    20
    Post Thanks / Like

    Audi A3 8V Auto hold (ABS module) - Anyone figure this out yet?

    Sorry to post this as it has been asked before, but I thought I could consolidate all of the data into one post to be helpful, and ask if anyone has made any progress on this.


    I'm trying to get Auto Hold enabled (this function causes the brakes to remain 'on' when the vehicle is stopped, so that you do not have to hold the brake pedal at lights, in traffic, etc).
    I know it seems like a silly thing, but drive around every day in NYC and you'll realize how useful it can be. I miss it from my previous car (a Mercedes C class).

    Vehicle is a 2016 A3 (8V) US model.

    This is the modification in question:
    Code:
    Adaptation of the functional state of the Auto Hold setting - NOT TESTED
    --------------------
    [03] Brakes Electronics -> Adaptation ->
    Select AUTO HOLD function state -> Set value: (Default: last setting)
    Last setting: AUTO HOLD uses the last defined setting which was set over the button
    never active: AUTOHOLD not automatically activated
    always active: AUTO HOLD always enabled
    These are the security codes we know of for this ABS module, and I have tried them all with the following results:

    Code:
    ABS CODES ATTEMPTED FOR AUTO HOLD ADAPTATION CHANNEL:
    18573   'controller refused the key'
    44595   'controller ref the key'
    28183   'invalid key!'
    11966  engine on - 'sec access req'                    	engine off - 'sec access req'
    15081  engine on - 'sec access req'			engine off - 'sec access req'
    20103  engine on - 'sec access req'			engine off - 'sec access req'
    24435  engine on - 'sec access req'			engine off - 'sec access req'
    25004  engine on - 'sec access req'			engine off - 'sec access req'
    31857  engine on - 'sec access req'			engine off - 'sec access req'
    37202  engine on - 'sec access req'			engine off - 'sec access req'
    40168  engine on - 'sec access req'                     engine off - 'sec access req'
    11966  engine on - 'sec access req'			engine off - 'sec access req'
    This is the autoscan for my vehicle:
    Code:
    Wednesday,28,October,2015,15:33:09:59061
    VCDS -- Windows Based VAG/VAS Emulator Running on Windows 8 x64
    VCDS Version: 15.7.1.0 (x64)
    Data version: 20150904
    www.Ross-Tech.com


    VIN: WAUE8GFF0G1017868   License Plate:
    Mileage: 1113km-691mi   Repair Order:



    --------------------------------------------------------------------------------
    --------------------------------------------------------------------------------


    Chassis Type: FF (5Q0)
    Scan: 01 02 03 05 08 09 10 15 16 17 19 22 2B 3C 42 44 52 55 5F 6C


    VIN: WAUE8GFF0G1017868   Mileage: 1113km-691miles

    01-Engine -- Status: OK 0000
    02-Auto Trans -- Status: OK 0000
    03-ABS Brakes -- Status: OK 0000
    05-Acc/Start Auth. -- Status: OK 0000
    08-Auto HVAC -- Status: OK 0000
    09-Cent. Elect. -- Status: OK 0000
    10-Park/Steer Assist -- Status: OK 0000
    15-Airbags -- Status: OK 0000
    16-Steering wheel -- Status: OK 0000
    17-Instruments -- Status: OK 0000
    19-CAN Gateway -- Status: OK 0000
    22-AWD -- Status: OK 0000
    2B-Steer. Col. Lock -- Status: OK 0000
    3C-Lane Change -- Status: OK 0000
    42-Door Elect, Driver -- Status: OK 0000
    44-Steering Assist -- Status: OK 0000
    52-Door Elect, Pass. -- Status: OK 0000
    55-Headlight Range -- Status: OK 0000
    5F-Information Electr. -- Status: OK 0000
    6C-Back-up Cam. -- Status: OK 0000

    -------------------------------------------------------------------------------
    Address 01: Engine (J623-CNTC)       Labels: 06K-907-425-V1.clb
       Part No SW: 5G0 906 259 D    HW: 06K 907 425 B
       Component: 2.0l R4 TFSI  H13 0001
       Revision: --H13---
       Coding: 0A1D00124426000F3000
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_ECM20TFS0205G0906259D 001002
       ROD: EV_ECM20TFS0205G0906259D_AU37.rod
       VCID: 2F43E1BA76FBF946F4-807A

    No fault code found.
    Readiness: 0000 0000

    -------------------------------------------------------------------------------
    Address 02: Auto Trans (J743)       Labels: 0D9-927-770.clb
       Part No SW: 0D9 300 013 B    HW: 02E 927 770 AQ
       Component: DQ250-6A MQB  H53 4902
       Revision: 06253104    Serial number: TFK01506151418
       Coding: 0014
       Shop #: WSC 04742 780 00200
       ASAM Dataset: EV_TCMDQ250021 001001
       ROD: EV_TCMDQ250021_AU37.rod
       VCID: 160D345EE961288E97-8042

    1 Fault Found:
    10657 - RPM Signal from ECU
              P0726 00 [002] - Implausible Signal
              Intermittent - Not Confirmed - Tested Since Memory Clear
                 Freeze Frame:


    -------------------------------------------------------------------------------
    Address 03: ABS Brakes (J104)       Labels: 5Q0-907-379-IPB-V1.clb
       Part No SW: 3Q0 907 379 AA    HW: 3Q0 907 379 F
       Component: ESC           H42 0623
       Revision: 00000000    Serial number: 61705000003059
       Coding: 13FF6A9234210A73017F030681CB29C8562C5080C08194B6024100548208
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_Brake1UDSContiMK100IPB 034036
       ROD: EV_Brake1UDSContiMK100IPB_AU37.rod
       VCID: 79D71FE2F83FE7F61A-802C

    No fault code found.

    -------------------------------------------------------------------------------
    Address 05: Acc/Start Auth. (J518)       Labels: 5Q0-959-435.clb
       Part No SW: 5Q0 959 435 A    HW: 5Q0 959 435
       Component: VWKESSYMQB    021 0604
       Revision: 00021000    Serial number: 0371172870
       Coding: 030C0C
       Shop #: WSC 00000 000 00000
       ASAM Dataset: EV_KessyHellaMQBAB 002011
       ROD: EV_KessyHellaMQBAB_AU37.rod
       VCID: 3A55C0EEBDB92CEE53-806E

    No fault code found.

    -------------------------------------------------------------------------------
    Address 08: Auto HVAC (E87)       Labels: 8V0-820-043.clb
       Part No SW: 8V0 820 043 D    HW: 8V0 820 043 D
       Component: AC Automat    H13 0060
       Revision: 20027000    Serial number: 00000000675584
       Coding: 03000014010000000000000000001400
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_AirCondiFrontVaAU37X 008020
       ROD: EV_AirCondiFrontVaAU37X.rod
       VCID: 334BEDCA9AD3DDA690-8066

    No fault code found.

    -------------------------------------------------------------------------------
    Address 09: Cent. Elect. (J519)       Labels: None
       Part No SW: 5Q0 937 085 AH    HW: 5Q0 937 085 AE
       Component: BCM MQBAB MNA H24 0175
       Serial number: 01061517300062
       Coding: 04151A46C04122F541C04004511007000800000000000000000000000000
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_BCMMQB 015001
       ROD: EV_BCMBOSCH_AU37.rod
       VCID: 7F23F1FAE61BC9C624-802A

       Slave 1:
       Subsystem 1 - Part No SW: 8V1 955 119 C    HW: 8V1 955 119 A  Labels: 5QX-955-119-V1.CLB
       Component: WWS371 150622  042 0585
       Serial number:         150626163354
       Coding: 0A47F7

       Slave 2:
       Subsystem 2 - Part No SW: 8U0 955 559 B    HW: 8U0 955 559 B  Labels: 8U0-955-559.CLB
       Component: G397_RLFS  H06 0002
       Serial number: 24033012
       Coding: 00006C

       Slave 3:
       Subsystem 3 - Part No SW: 8V0 941 531 AD    HW: 8V0 941 531 AD
       Component: E1 - LDS MQB  H05 0032
       Serial number: 24 04 2015  00001464

       Subsystem 4 - Part No SW: 5Q0 951 605     HW: 5Q0 951 605
       Component: Sirene, DWA  004 0311
       Serial number: 00000000000032761900

       Subsystem 5 - Part No SW: 8V3 959 591 A    HW: 8V3 959 591 A
       Component: J245 PS73.404  H03 0004
       Serial number: 0000FST000DCYI500000
       Coding: 101F00

    No fault code found.

    -------------------------------------------------------------------------------
    Address 10: Park/Steer Assist (J791)       Labels: 5Q0-919-294.clb
       Part No SW: 5Q0 919 294 K    HW: 5Q0 919 294 A
       Component: PARKHILFE 8K  H03 0054
       Revision: --------    Serial number: 39391511401374
       Coding: 0030150011
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_EPHVA18AU3700000 002026
       ROD: EV_EPHVA18AU3700000_AU37.rod
       VCID: 43ABBD0ACA736D2600-8016

    No fault code found.

    -------------------------------------------------------------------------------
    Address 15: Airbags (J234)       Labels: 5Q0-959-655.clb
       Part No SW: 5Q0 959 655 J    HW: 5Q0 959 655 J
       Component: AirbagVW20    010 0830
       Serial number: 003GCR02FMY2
       Coding: 9DCCFCC0000000005000001AC24800000065
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_AirbaVW20SMEVW37X 002144
       ROD: EV_AirbaVW20SMEVW37X_AU37.rod
       VCID: 47B3A91AFE4B4106DC-8012

       Seat belt tensioner; left:
       Subsystem 1 - Part No SW: 5G0 980 945 B    HW: 5G0 980 945 B
       Component: BeltPretRevFL  H36 0350
       Serial number: 34178311B26061540731
       Coding: 333135

       Seat belt tensioner; right:
       Subsystem 2 - Part No SW: 5G0 980 946 B    HW: 5G0 980 946 B
       Component: BeltPretRevFR  H36 0350
       Serial number: 34178312B26061571183
       Coding: 333135

       Seat occupant detection; front passenger side:
       Subsystem 3 - Part No SW: 5C6 959 339 B    HW: 5C6 959 339 B
       Component: BF-Gewichtss.  H10 0046
       Serial number: 694000000000001D0LNY
       Coding: 303333

       Crash sensor for side airbag; driver side:
       Subsystem 4 - Part No SW: -----------    HW: 480 001 906 15
       Component: SideSensor_Df  001 0887
       Serial number: 35700000000570392514
       Coding: 2D2D2D

       Crash sensor for side airbag; front passenger side:
       Subsystem 5 - Part No SW: -----------    HW: 480 001 906 15
       Component: SideSensor_Pf  001 0887
       Serial number: 358000000001D1392518
       Coding: 2D2D2D

       Crash sensor for side airbag; rear; driver side:
       Subsystem 6 - Part No SW: -----------    HW: 480 401 606 15
       Component: SideSensor_Dr  001 6149
       Serial number: 3510002991B5A870518%
       Coding: 2D2D2D

       Crash sensor for side airbag; rear; passenger side:
       Subsystem 7 - Part No SW: -----------    HW: 480 402 306 15
       Component: SideSensor_Pr  001 6149
       Serial number: 3520002B11B65D50A14.
       Coding: 2D2D2D

       Crash sensor for front airbag; driver side:
       Subsystem 8 - Part No SW: -----------    HW: 480 402 502 15
       Component: FrontSensor_D  001 6149
       Serial number: 35500029919DB8B522AJ
       Coding: 2D2D2D

       Crash sensor for front airbag; front passenger side:
       Subsystem 9 - Part No SW: -----------    HW: 480 402 502 15
       Component: FrontSensor_P  001 6149
       Serial number: 3560002BD19DB8B250AO
       Coding: 2D2D2D

    No fault code found.

    -------------------------------------------------------------------------------
    Address 16: Steering wheel (J527)       Labels: 5Q0-953-549.clb
       Part No SW: 8V0 953 521 FH    HW: 5Q0 953 549 E
       Component: Lenks. Modul  003 0110
       Revision: --------    Serial number: 28061508490273
       Coding: A018
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_SMLSKLOMQB 017001
       ROD: EV_SMLSKLOMQB_AU37.rod
       VCID: 052F631284C793166E-8050

    No fault code found.

    -------------------------------------------------------------------------------
    Address 17: Instruments (J285)       Labels: 5G0-920-XXX-17.clb
       Part No SW: 8V0 920 971 Q    HW: 8V0 920 971 Q
       Component: KOMBI         H03 6420
       Coding: 0BED18192B88D7050200EA001800000000000000
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_DashBoardVDDMQBAB 009046
       ROD: EV_DashBoardVDDMQBAB_AU37.rod
       VCID: 4BBB952AE223A566F8-801E

    No fault code found.

    -------------------------------------------------------------------------------
    Address 19: CAN Gateway (J533)       Labels: 5Q0-907-530-V1.clb
       Part No SW: 5Q0 907 530 AF    HW: 5Q0 907 530 M
       Component: GW MQB High   212 2223
       Revision: --------    Serial number: 24061510803255
       Coding: 0101000830085A005B00020C180B00000001010000000000000000000000
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_GatewConti 013020
       ROD: EV_GatewConti.rod
       VCID: 75CF13D2D42783967E-8020

       Alternator:

       Multifunction unit control module:
       Subsystem 2 - Part No SW: 8U0 951 528 A    HW: 8U0 951 528 A
       Component: E221 - MFL  H02 0014
       Serial number: 18 06 2015  D0050891

    No fault code found.

    -------------------------------------------------------------------------------
    Address 22: AWD (J492)       Labels: 0CQ-907-554.clb
       Part No SW: 0CQ 907 554 D    HW: 0CQ 525 130
       Component: Haldex4Motion H52 7082
       Serial number: HA1-00025.03.15
       Coding: 0001
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_AllWheelContrHA1VW37X 002013
       ROD: EV_AllWheelContrHA1VW37X_AU21.rod
       VCID: 46ADA41EF941580E27-8012

    No fault code found.

    -------------------------------------------------------------------------------
    Address 2B: Steer. Col. Lock (J764)       Labels: 5Q0-905-861.clb
       Part No SW: 5Q0 905 861 A    HW: 5Q0 905 861 A
       Component: ELV-MQBA      H01 0120
       Revision: 00000000    Serial number: 15000162954002
       Coding: 5D00000000000000
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_ELVMarquMQB 004111
       ROD: EV_ELVMarquMQB_AU37.rod
       VCID: 3449EED69FDDDA9E89-8060

    No fault code found.

    -------------------------------------------------------------------------------
    Address 3C: Lane Change (J769)       Labels: 5Q0-907-566.clb
       Part No SW: 5Q0 907 566 A    HW: 8T0 907 566 B
       Component: SWA Master    H05 0080
       Serial number: 0368931344
       Coding: 030211
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_LaneChangAssis 001020
       ROD: EV_LaneChangAssis_AU37.rod
       VCID: 3851DAE683B53EFEA5-806C

       Lane Change Assistant 2:

    No fault code found.

    -------------------------------------------------------------------------------
    Address 42: Door Elect, Driver (J386)       Labels: None
       Part No SW: 5Q0 959 393 E    HW: 5Q0 959 393 B
       Component: TSG FS        020 0041
       Serial number: 070615BF611299
       Coding: 00101B204000048000000002
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_DCUDriveSideEWMINKLO 006003
       ROD: EV_DCUDriveSideEWMAXCONT_AU37.rod
       VCID: 41A7B702D06F7F3612-8014

    No fault code found.

    -------------------------------------------------------------------------------
    Address 44: Steering Assist (J500)       Labels: 5Q0-909-144.clb
       Part No SW: 5Q0 909 144 R    HW: 5Q0 909 144 R
       Component: EPS_MQB_ZFLS  126 1061
       Coding: 0102
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_SteerAssisMQB 012140
       ROD: EV_SteerAssisMQB.rod
       VCID: 43ABBD0ACA736D2600-8016

    No fault code found.

    -------------------------------------------------------------------------------
    Address 52: Door Elect, Pass. (J387)       Labels: None
       Part No SW: 5Q0 959 392 E    HW: 5Q0 959 392 B
       Component: TSG BFS       020 0041
       Serial number: 070615BF615066
       Coding: 001013204000048000000002
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_DCUPasseSideEWMINKLO 006003
       ROD: EV_DCUPasseSideEWMAXCONT_AU37.rod
       VCID: 40A1B206DB65763E1D-8014

    No fault code found.

    -------------------------------------------------------------------------------
    Address 55: Headlight Range (J431)       Labels: 5Q0-907-357.clb
       Part No SW: 5Q0 907 357     HW: 6R0 907 357 A
       Component: LWR-ECU       005 0080
       Revision: --------    Serial number: --------------
       Coding: 012A000101000000
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_HeadlRegulVWLWRMQB 001110
       ROD: EV_HeadlRegulVWLWRMQB_AU37.rod
       VCID: 75CF13D2D42783967E-8020

    No fault code found.

    -------------------------------------------------------------------------------
    Address 5F: Information Electr. (J794)       Labels: None
       Part No SW: 8V0 035 038 B    HW: 8V0 035 038 B
       Component: MU-H-LNS-US   H43 0394
       Serial number: A302F0FB015010
       Coding: 01730102FF0A000021220001041A00102F000105010001047E
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_MUHig6C3HBAS 001040
       ROD: EV_MUHig6C3HBAS_AU37.rod
       VCID: 334BEDCA9AD3DDA690-8066

       Engine Control Module 2:
       Subsystem 1 - Part No SW: V03 959 800 SS    HW: -----------
       Component: NAR 2015  --- 0035
       Serial number: --------------------

       Seat Adjustment Driver Side:
       Subsystem 2 - Part No SW: 8V0 919 604 C    HW: 8V0 919 604 C
       Component: DU High  H49 0014
       Serial number: AUZ8Z9FY203DZ3

       Sound System:
       Subsystem 3 - Part No SW: 8V0 919 614 L    HW: 8V0 919 614 L
       Component: ControlUnit_H  H81 0816
       Serial number: C1000029041500030337

       Door Electronics Rear Left:
       Subsystem 4 - Part No SW: V03 959 800 EG    HW: -----------
       Component: Gracenote  --- 3006
       Serial number: --------------------

    No fault code found.

    -------------------------------------------------------------------------------
    Address 6C: Back-up Cam. (J772)       Labels: 5Q0-907-441.clb
       Part No SW: 5Q0 907 441 A    HW: 5Q0 907 441 A
       Component: MQB RVC Mid   H07 0140
       Coding: 027300010201000300
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_2CamSysRearPASE 006016
       ROD: EV_CamSysRearPANAAU914.rod
       VCID: 3041E2C66BC5E6BEED-8064

    No fault code found.

    End-------------------------(Elapsed Time: 03:40)--------------------------
    I have also mapped the adaptations for every channel, if the files would be of any help I can send them.
    Is there any way to crack this nut? I'm willing to test pretty much anything to help out if possible.

  2. #2
    VCDS Distributor
    Join Date
    Feb 2014
    Location
    Denmark
    Posts
    1,680
    Post Thanks / Like
    Maybe buy a new ABS ?
    My guess is, you need an ABS that has PR-UH2 (PR code), your ABS controller has PR-UH1.

  3. Likes Uwe liked this post
  4. #3
    Verified VCDS User
    Join Date
    Oct 2015
    Location
    USA
    Posts
    20
    Post Thanks / Like
    Curious where this info came from? I was (and am) under the impression that it's just a matter of finding the security code, as it has been on other models. The ABS module has all the necessary hardware as far as I know.

  5. #4
    Verified VCDS User
    Join Date
    Mar 2014
    Location
    Slovenia
    Posts
    127
    Post Thanks / Like
    Just a question: so you would like to have Auto Hold and not Hill Hold activated?
    Because according to my info, Hill Hold (3s auto braking on hill) should be already active with DSG transmission.

  6. #5
    Verified VCDS User
    Join Date
    Oct 2015
    Location
    USA
    Posts
    20
    Post Thanks / Like
    No, why would I not want hill hold?
    I simply want to enable auto hold, which I know is already available with this ABS module and requires no hardware changes (except for the button which is optional)
    Hill hold still remains active for auto braking on a hill as you pointed out.

  7. #6
    Verified VCDS User
    Join Date
    Oct 2015
    Location
    USA
    Posts
    20
    Post Thanks / Like

    2016 A3 Auto Hold Security Code Found! Only more questions though...

    Ok so credit to DJAlix for finding the ABS security code (24990) for the channel AUTO HOLD Functionality.

    With this code, I was able to change it to "active".
    I expected to find another adaptation channel "AUTO HOLD function state" which can be set to "last setting" "never active" or "always active". Without that setting available, I do not believe auto hold can be turned on short of installing the button.

    Anyone? At least it's progress...

    EDIT: Some more info...

    This is the adaptation map with the "AUTO HOLD functional status" channel that I was expecting:
    Code:
    ;SW:5Q0-907-379-AC HW:5Q0-907-379-D --- ABS Brakes
    ;Component:ESC H75 0437	Coding:01FA8AA1202312700377060701C32980510448C0608094F3002A0028C1
    ;EV_Brake1UDSContiMK100IPB	8020	EV_Brake1UDSContiMK100IPB_AU37.rod
    ;Saturday	2	August	2014
    ;VCDS Version: Release 12.12.0 Data version: 20130910
    ;VCID: 7DF1154CECFCAFF6FF5-8028
    ;With access code for module controller

    ABS in lower speed range	activated
    Activating and deactivating all development messages	0
    AUTO HOLD functional status	Last setting
    AUTO HOLD functionality	not activated
    AUTO HOLD increase threshold; full tensioning force	10%
    AUTO HOLD increase threshold; reduced tensioning force	0%
    AUTO HOLD slippage recognition	activated
    This is what I am getting on my vehicle:
    Code:
    ;SW:3Q0-907-379-AA   HW:3Q0-907-379-F ---  ABS Brakes
    ;Component:ESC           H42 0623	 Coding:13FF6A9234210A73017F030681CB29C8562C5080C08194B6024100548208
    ;EV_Brake1UDSContiMK100IPB	34036	EV_Brake1UDSContiMK100IPB_AU37.rod
    ;Wednesday	28	October	2015	15:34:54:59061
    ;VCDS Version: Release 15.7.1 (x64)  Data version: 20150904
    ;VCID: 79D71FE2F83FE7F61A-802C

    Activating and deactivating all development messages	not active
    AUTO HOLD functionality	not activated 	       [OK, this line now says activated, posting an older admap here, but otherwise identical]
    AUTO HOLD increase threshold; full tensioning force	10%
    AUTO HOLD increase threshold; reduced tensioning force	0%
    AUTO HOLD slippage recognition	activated
    Last edited by ineedbeer; 04-12-2016 at 04:13 PM.

  8. Likes Uwe liked this post
  9. #7
    Verified VCDS User
    Join Date
    Jun 2014
    Location
    UK
    Posts
    56
    Post Thanks / Like
    We have been looking into this for a while.
    I have scanned 2 vehicles (mk7 golfs) both with auto hold, neither of them had the "auto hold" adaptation set to active.

    This leads me to believe the function lies in the coding of the module and not the adaptation channels, despite my best efforts I cannot makes many changes to the coding without the error "coding rejected, out of range"

  10. Likes ineedbeer liked this post
  11. #8
    Verified VCDS User
    Join Date
    Jun 2014
    Location
    UK
    Posts
    56
    Post Thanks / Like
    I can confirm that this function is not in the adaptations.
    As a test I have set my channels to "active" for AUTO-HOLD and "always" for when to be active as I don't have a switch. This doesn't work.



  12. Likes ineedbeer, jnvwtechacct liked this post
  13. #9
    Verified VCDS User
    Join Date
    May 2014
    Location
    Melbourne, Australia
    Posts
    2,688
    Post Thanks / Like
    ineedbeer: Further input if needed. Here are a section of the admaps for the ABS from my database for a couple of Aussie cars- both of which have auto-hold factory fitted



    And here is a simplified WD for how the button operates- looks like a simple switch +12V supply to PN#23! I suspect that once the Auto-hold switch is fitted, all that's needed is to tell J104 about the fitment (probably by a code change as has been previously suggested). Problem is that the ABS module doesn't have a long Coding Helper screen set as yet! The other problem is that there is an intimate arrangement between the Auto-hold function and EPB (the console switched for two functions work together), but this might not be pertinent if your vehicle has a mechanical hand-brake
    Don

    Last edited by DV52; 04-13-2016 at 08:41 AM.
    VW Golf MkVII (MY13) - A3 8V hatch (MY17)

  14. Likes ineedbeer liked this post
  15. #10
    Verified VCDS User
    Join Date
    Nov 2014
    Location
    San José, Costa Rica
    Posts
    112
    Post Thanks / Like
    Hello all,

    Maybe someone can work some hexadecimal magic and come up with a coding suggestion in order to activate auto hold (not hill hold, that one is already on all 8Vs).
    Here is a reference scan from a friends A3 that has auto hold fitted from the factory.
    Code:
    Monday,18,April,2016,18:14:58:29892
    VCDS -- Windows Based VAG/VAS Emulator Running on Windows 10 x64
    VCDS Version: 16.3.0.0 (x64)
    Data version: 20160216
    www.Ross-Tech.com


    VIN: WAUZZZ8V3EA000770   License Plate: MVL100
    Mileage: 33717km-20950mi   Repair Order:



    --------------------------------------------------------------------------------
    --------------------------------------------------------------------------------


    Chassis Type: 8V (5Q0)
    Scan: 01 03 08 09 15 16 17 19 42 44 52 55 5F

    VIN: WAUZZZ8V3EA000770   Mileage: 33717km-20950miles

    01-Engine -- Status: OK 0000
    03-ABS Brakes -- Status: OK 0000
    08-Auto HVAC -- Status: Malfunction 0010
    09-Cent. Elect. -- Status: Malfunction 0010
    15-Airbags -- Status: OK 0000
    16-Steering wheel -- Status: OK 0000
    17-Instruments -- Status: OK 0000
    19-CAN Gateway -- Status: OK 0000
    42-Door Elect, Driver -- Status: OK 0000
    44-Steering Assist -- Status: OK 0000
    52-Door Elect, Pass. -- Status: OK 0000
    55-Headlight Range -- Status: OK 0000
    5F-Information Electr. -- Status: Malfunction 0010

    -------------------------------------------------------------------------------
    Address 01: Engine (J623-CJZA)       Labels: 04E-907-309-V1.clb
       Part No SW: 04E 906 016 B    HW: 04E 907 309 A
       Component: 1.2l R4 TSI   H08 5544
       Revision: WAH08---
       Coding: 02110012230400082000
       Shop #: WSC 06314 790 00021
       ASAM Dataset: EV_ECM12TFS01104E906016B 001006
       ROD: EV_ECM12TFS01104E906016B.rod
       VCID: 2149CBAF30BD2E3480-8074

    No fault code found.
    Readiness: 0000 0000

    -------------------------------------------------------------------------------
    Address 03: ABS Brakes (J104)       Labels: 5Q0-907-379-IPB-V1.clb
       Part No SW: 5Q0 907 379 P    HW: 5Q0 907 379 D
       Component: ESC           H75 0434
       Revision: 00000000    Serial number:
       Coding: 10F16AA220200A6C037E060701C32508560450C06080A4B30039000805
       Shop #: WSC 05212 002 104857
       ASAM Dataset: EV_Brake1UDSContiMK100IPB 008020
       ROD: EV_Brake1UDSContiMK100IPB_AU37.rod
       VCID: 4999730FE8CDC67438-801C

    No fault code found.

    -------------------------------------------------------------------------------
    Address 08: Auto HVAC (E87)       Labels: 8V0-820-047.clb
       Part No SW: 8V0 820 047 B    HW: 8V0 820 047 B
       Component: AC Manuell el H09 0031
       Revision: 20017000    Serial number: 00000000014027
       Coding: 00000004100000000000000000000000
       Shop #: WSC 06314 790 00021
       ASAM Dataset: EV_AirCondiFrontManAU37X 008016
       ROD: EV_AirCondiFrontManAU37X.rod
       VCID: 35610FFF9435B2944C-8060

    1 Fault Found:
    1048833 - Function Limitation due to Compressor Shut-Off Request By Engine
              B10F0 00 [008] -  -
              Intermittent - Confirmed - Tested Since Memory Clear
                 Freeze Frame:
                        Fault Status: 00000001
                        Fault Priority: 6
                        Fault Frequency: 7
                        Reset counter: 171
                        Mileage: 32445 km
                        Date: 2016.03.14
                        Time: 09:23:57

                        Voltage terminal 30: 13.9 V
                        Compressor shut-off requirement: Shut-off from Engine Control Module (ECM) via CAN


    -------------------------------------------------------------------------------
    Address 09: Cent. Elect. (J519)       Labels: 5Q0-937-08X-HV1.clb
       Part No SW: 5Q0 937 084 Q    HW: 5Q0 937 084 Q
       Component: BCM MQBAB H   H14 0106
       Serial number: 00011311700298
       Coding: 04000A42C001227D03044000B30C07000000000000000000000000000000
       Shop #: WSC 06314 790 00021
       ASAM Dataset: EV_BCMCONTI 010001
       ROD: EV_BCMBOSCH_VW37.rod
       VCID: 46837833F9D3290CD5-8012

       Slave 1:
       Subsystem 1 - Part No SW: 8V1 955 119 A    HW: 8V1 955 119   Labels: 5QX-955-119-V1.CLB
       Component: WWS370 130418  041 0580
       Serial number:         130423140117
       Coding: 0A47F7

       Slave 2:
       Subsystem 2 - Part No SW: 8U0 955 559 A    HW: 8U0 955 559 A  Labels: 8U0-955-559.CLB
       Component: G397_RLS  H06 0002
       Serial number: 20114803
       Coding: 06885D

       Slave 3:
       Subsystem 3 - Part No SW: 8V0 941 531 L    HW: 8V0 941 531 L
       Component: E1 - LDS MQB  H05 0032
       Serial number: 16 04 2013  00001858

       Subsystem 4 - Part No SW: 8V0 951 177     HW: 5Q0 951 172
       Component: Sensor, DWA  005 0313
       Serial number: 000000000ZY130931L14

       Subsystem 5 - Part No SW: 5Q0 951 605     HW: 5Q0 951 605
       Component: Sirene, DWA  004 0311
       Serial number: 00000000000056638894

    1 Fault Found:
    197644 - Control Circuit for Fuel Tank Flap
              B1263 01 [008] - Electrical Failure
              Intermittent - Confirmed - Tested Since Memory Clear
                 Freeze Frame:
                        Fault Status: 00000001
                        Fault Priority: 4
                        Fault Frequency: 13
                        Reset counter: 172
                        Mileage: 1048574 km
                        Date: 2000.00.00
                        Time: 00:00:00


    -------------------------------------------------------------------------------
    Address 15: Airbags (J234)       Labels: 5Q0-959-655.clb
       Part No SW: 5Q0 959 655 L    HW: 5Q0 959 655 L
       Component: AirbagVW20    009 0349
       Serial number: 003GER00ZWUS
       Coding: 98CCC000000000005C540000004800000065
       Shop #: WSC 06314 790 00021
       ASAM Dataset: EV_AirbaVW20SMEVW37X 002126
       ROD: EV_AirbaVW20SMEVW37X_VW37.rod
       VCID: 4999730FE8CDC67438-801C

       Side Sensor Driver Front:
       Subsystem 1 - Part No SW: -----------    HW: 480 002 204 13
       Component: SideSensor_Df  001 0887
       Serial number: 3576700000033C688C0.
       Coding: 2D2D2D

       Side Sensor Passenger Front:
       Subsystem 2 - Part No SW: -----------    HW: 480 002 204 13
       Component: SideSensor_Pf  001 0887
       Serial number: 3586700000013D688C0.
       Coding: 2D2D2D

       Side Sensor Driver Rear:
       Subsystem 3 - Part No SW: -----------    HW: 480 400 904 13
       Component: SideSensor_Dr  001 6149
       Serial number: 3516502A90FBDE45B21V
       Coding: 2D2D2D

       Side Sensor Passenger Rear:
       Subsystem 4 - Part No SW: -----------    HW: 480 400 904 13
       Component: SideSensor_Pr  001 6149
       Serial number: 3526502AF0FBDE32738
       Coding: 2D2D2D

       Front Sensor Driver:
       Subsystem 5 - Part No SW: -----------    HW: 480 401 403 13
       Component: FrontSensor_D  001 6149
       Serial number: 3556502A10FAE894404J
       Coding: 2D2D2D

    No fault code found.

    -------------------------------------------------------------------------------
    Address 16: Steering wheel (J527)       Labels: 5Q0-953-549.clb
       Part No SW: 8V0 953 521     HW: 5Q0 953 549 A
       Component: Lenks. Modul  007 0070
       Revision: --------    Serial number: 25041304221057
       Coding: 8408
       Shop #: WSC 06314 790 00021
       ASAM Dataset: EV_SMLSKLOMQB 009001
       ROD: EV_SMLSKLOMQB_AU37.rod
       VCID: 77FDC5F7CEB980849E-8022

    No fault code found.

    -------------------------------------------------------------------------------
    Address 17: Instruments (J285)       Labels: 5G0-920-XXX-17.clb
       Part No SW: 8V0 920 860     HW: 8V0 920 860
       Component: KOMBI         H22 0570
       Coding: 078502002A8000080500AA00000000
       Shop #: WSC 06314 790 00021
       ASAM Dataset: EV_DashBoardVDDMQBAB 008026
       ROD: EV_DashBoardVDDMQBAB_AU37.rod
       VCID: 77FDC5F7CEB980849E-8022

    No fault code found.

    -------------------------------------------------------------------------------
    Address 19: CAN Gateway (J533)       Labels: 5Q0-907-530-V1.clb
       Part No SW: 5Q0 907 530 J    HW: 5Q0 907 530 F
       Component: GW MQB High   125 1126
       Revision: --------    Serial number: 0000575131
       Coding: 010100F02008640000000200000B00000001000000000000000000000000
       Shop #: WSC 06314 790 00021
       ASAM Dataset: EV_GatewLear 008010
       ROD: EV_GatewLear.rod
       VCID: 387F06CB83274FFC57-806C

       Generator:

       Multifunction unit control module:
       Subsystem 2 - Part No SW: 8U0 951 528     HW: 8U0 951 528
       Component: E221 - MFL  H02 0014
       Serial number: 27 04 2013  A1163564

    No fault code found.

    -------------------------------------------------------------------------------
    Address 42: Door Elect, Driver (J386)       Labels: 5QX-959-X93-42.clb
       Part No SW: 5Q0 959 393 A    HW: 5Q0 959 393
       Component: TSG FS        012 0006
       Serial number: 19041301100036
       Coding: 00100E204100040100001002
       Shop #: WSC 06314 790 00021
       ASAM Dataset: EV_DCUDriveSideEWMINKLO 006003
       ROD: EV_DCUDriveSideEWMAXCONT.rod
       VCID: 3D7117DFAC056AD484-8068

    No fault code found.

    -------------------------------------------------------------------------------
    Address 44: Steering Assist (J500)       Labels: 5Q0-909-144.clb
       Part No SW: 5Q0 909 144 L    HW: 5Q0 909 144 L
       Component: EPS_MQB_ZFLS  119 1021
       Coding: 01
       Shop #: WSC 06314 790 00021
       ASAM Dataset: EV_SteerAssisMQB 008022
       ROD: EV_SteerAssisMQB_VW37.rod
       VCID: 3D7117DFAC056AD484-8068

    No fault code found.

    -------------------------------------------------------------------------------
    Address 52: Door Elect, Pass. (J387)       Labels: 5QX-959-X92-52.clb
       Part No SW: 5Q0 959 392 A    HW: 5Q0 959 392
       Component: TSG BFS       012 0006
       Serial number: 08041301100276
       Coding: 001006204500040100001002
       Shop #: WSC 06314 790 00021
       ASAM Dataset: EV_DCUPasseSideEWMINKLO 006003
       ROD: EV_DCUPasseSideEWMAXCONT.rod
       VCID: 3C771ADBB71F63DCB3-8068

    No fault code found.

    -------------------------------------------------------------------------------
    Address 55: Headlight Range (J431)       Labels: 5Q0-907-357.clb
       Part No SW: 5Q0 907 357     HW: 6R0 907 357 A
       Component: LWR-ECU       005 0070
       Revision: --------    Serial number: --------------
       Coding: 010A000001000000
       Shop #: WSC 08960 001 1048576
       ASAM Dataset: EV_HeadlRegulVWLWRMQB 001110
       ROD: EV_HeadlRegulVWLWRMQB_AU37.rod
       VCID: 75E1CFFFD4B5F2948C-8020

    No fault code found.

    -------------------------------------------------------------------------------
    Address 5F: Information Electr. (J794)       Labels: 8V0-035-MIB-STD1.clb
       Part No SW: 8V0 035 840 A    HW: 8V0 035 840
       Component: MU-S--ER      039 0370
       Serial number: A3E00105130061
       Coding: 01730000FF0A000021220001001A00002F0001440100010002
       Shop #: WSC 06314 790 00021
       ASAM Dataset: EV_MUStd6C3PASE 002020
       ROD: EV_MUStd6C3PASE_AU37.rod
       VCID: 336531E79A41ACA462-8066

       Seat Adjustment Driver Side:
       Subsystem 1 - Part No SW: 8V0 919 603 A    HW: 8V0 919 603 A
       Component: DU Std  H47 0013
       Serial number: AUZ8Z9DG600T0N

       Sound System:
       Subsystem 2 - Part No SW: 8V0 919 614 B    HW: 8V0 919 614 B
       Component: ControlUnit_B  H33 0037
       Serial number: C1000013031300020231

    2 Faults Found:
    0532 - Subwoofer
              B106C 13 [009] - Open Circuit
              Confirmed - Tested Since Memory Clear
                 Freeze Frame:
                        Fault Status: 00000001
                        Fault Priority: 6
                        Fault Frequency: 1
                        Reset counter: 246
                        Mileage: 31378 km
                        Date: 2016.02.05
                        Time: 08:21:11

    6179 - Display Module 1 for Multimedia System
              B1297 F6 [008] - Cable for Video Signal; Open Circuit
              Intermittent - Confirmed - Tested Since Memory Clear
                 Freeze Frame:
                        Fault Status: 00000001
                        Fault Priority: 4
                        Fault Frequency: 1
                        Reset counter: 156
                        Mileage: 33429 km
                        Date: 2016.04.09
                        Time: 21:18:59


    End-------------------------(Elapsed Time: 02:58)--------------------------

    --------------------------------------------------------------------------------
    --------------------------------------------------------------------------------


    Address 5F:8V0 035 840 A recoded (ADP-(13)-Vehicle function list BAP-tire_pressure_system_0x07) from not activated  to activated

    --------------------------------------------------------------------------------
    --------------------------------------------------------------------------------


    Address 5F:8V0 035 840 A recoded (ADP-(14)-Vehicle function list BAP-tire_pressure_system_0x07_msg_bus) from Comfort data bus  to Suspension data bus

    --------------------------------------------------------------------------------
    --------------------------------------------------------------------------------


    Address 5F:8V0 035 840 A recoded (ADP-(56)-Vehicle menu operation-menu_display_rdk) from not activated  to activated

    --------------------------------------------------------------------------------
    --------------------------------------------------------------------------------


    Address 5F:8V0 035 840 A recoded (ADP-(58)-Vehicle menu operation-menu_display_rdk_over_threshold_high) from not activated  to activated

    --------------------------------------------------------------------------------
    --------------------------------------------------------------------------------


    Address 17:8V0 920 860  recoded (Long Coding) from 078502002A8000080500AA00000000 to 078502002B8000080500AA00000000  (06314/790/00021)
    --------------------------------------------------------------------------------
    --------------------------------------------------------------------------------


    Address 03:5Q0 907 379 P recoded (Long Coding) from 10F16AA220200A6C037E060701C32508560450C06080A4B30039000805 to 10F16AA220200A6C037E060701C32508560450C06080A4B30039003885  (05212/002/104857)
    --------------------------------------------------------------------------------
    --------------------------------------------------------------------------------

    Here is a reference scan of my new car, without auto-hold.
    Code:
    Monday,18,April,2016,20:53:00:29892
    VCDS -- Windows Based VAG/VAS Emulator Running on Windows 10 x64
    VCDS Version: 16.3.0.0 (x64)
    Data version: 20160216
    www.Ross-Tech.com


    VIN: WAUZZZ8V7H1000288   License Plate: TRS456
    Mileage: 2274km-1412mi   Repair Order:



    --------------------------------------------------------------------------------
    --------------------------------------------------------------------------------


    Chassis Type: 8V (5Q0)
    Scan: 01 02 03 08 09 10 15 16 17 19 42 44 52 55 5F

    VIN: WAUZZZ8V7H1000288   Mileage: 2274km-1412miles

    01-Engine -- Status: OK 0000
    02-Auto Trans -- Status: OK 0000
    03-ABS Brakes -- Status: OK 0000
    08-Auto HVAC -- Status: OK 0000
    09-Cent. Elect. -- Status: OK 0000
    10-Park/Steer Assist -- Status: OK 0000
    15-Airbags -- Status: OK 0000
    16-Steering wheel -- Status: OK 0000
    17-Instruments -- Status: OK 0000
    19-CAN Gateway -- Status: OK 0000
    42-Door Elect, Driver -- Status: OK 0000
    44-Steering Assist -- Status: OK 0000
    52-Door Elect, Pass. -- Status: OK 0000
    55-Headlight Range -- Status: OK 0000
    5F-Information Electr. -- Status: OK 0000

    -------------------------------------------------------------------------------
    Address 01: Engine (J623-CYVB)       Labels: 04E-907-309-V1.clb
       Part No SW: 04E 906 027 GR    HW: 04E 907 309 BL
       Component: R4 1.2l TFS   H23 2394
       Revision: R4H23---
       Coding: 02250012230400082000
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_ECM12TFS01104E906027GR 001005
       ROD: EV_ECM12TFS01104E906027GR.rod
       VCID: 7AFBDCC3FDAB9DECE1-802E

    No fault code found.
    Readiness: 0000 0000

    -------------------------------------------------------------------------------
    Address 02: Auto Trans (J743)       Labels: 0CW-927-769.clb
       Part No SW: 0CW 300 048 K    HW: 0AM 927 769 E
       Component: GSG DQ200G2_M H05 0614
       Revision: 00005005    Serial number: CU501512106812
       Coding: 0014
       Shop #: WSC 17734 418 534600
       ASAM Dataset: EV_TCMDQ200021 001001
       ROD: EV_TCMDQ200021.rod
       VCID: 4487623BCFEF1B1CCB-8010

    No fault code found.

    -------------------------------------------------------------------------------
    Address 03: ABS Brakes (J104)       Labels: 5Q0-907-379-IPB-V1.clb
       Part No SW: 3Q0 907 379 AA    HW: 3Q0 907 379 F
       Component: ESC           H42 0623
       Revision: 00000000    Serial number: 63625000001935
       Coding: 13F16AA22420126C0179060841CB25C8562448806082A4B2002100348208
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_Brake1UDSContiMK100IPB 034036
       ROD: EV_Brake1UDSContiMK100IPB_AU37.rod
       VCID: 79F9C3CFF8AD96F4E8-802C

    No fault code found.

    -------------------------------------------------------------------------------
    Address 08: Auto HVAC (E87)       Labels: 8V0-820-047.clb
       Part No SW: 8V0 820 047 D    HW: 8V0 820 047 D
       Component: AC Manuell el H11 0052
       Revision: 20021000    Serial number: 00000000187281
       Coding: 03000004100000000000000000000000
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_AirCondiFrontManAU37X 008018
       ROD: EV_AirCondiFrontManAU37X.rod
       VCID: 377D05F78E3940845E-8062

    No fault code found.

    -------------------------------------------------------------------------------
    Address 09: Cent. Elect. (J519)       Labels: 5Q0-937-08X-HV1.clb
       Part No SW: 5Q0 937 084 AS    HW: 5Q0 937 084 AN
       Component: BCM MQBAB H   H24 0175
       Serial number: 01061533701281
       Coding: 04041A42C041227D03A04004B10807000000000000000000000000000000
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_BCMMQB 015001
       ROD: EV_BCMBOSCH_VW37.rod
       VCID: 0919B30FA84D8674F8-805C

       Slave 1:
       Subsystem 1 - Part No SW: 8V1 955 119 C    HW: 8V1 955 119 A  Labels: 5QX-955-119-V1.CLB
       Component: WWS371 151118  043 0585
       Serial number:         151126161111
       Coding: 0A47F7

       Slave 2:
       Subsystem 2 - Part No SW: 8U0 955 559 D    HW: 8U0 955 559 A  Labels: 8U0-955-559.CLB
       Component: G397_RLS  H06 0004
       Serial number: 50030281
       Coding: 06885D

       Slave 3:
       Subsystem 3 - Part No SW: 8V0 941 531 AE    HW: 8V0 941 531 AE
       Component: E1 - LDS MQB  H05 0032
       Serial number: 17 10 2015  00000327

       Subsystem 4 - Part No SW: 8V0 951 177     HW: 5Q0 951 172
       Component: Sensor, DWA  005 0316
       Serial number: 000000000ZY153154N42

       Subsystem 5 - Part No SW: 5Q0 951 605 A    HW: 5Q0 951 605 A
       Component: Sirene, DWA  005 0313
       Serial number: 00000000000064431957

    No fault code found.

    -------------------------------------------------------------------------------
    Address 10: Park/Steer Assist (J446)       Labels: 5Q0-919-283.clb
       Part No SW: 5Q0 919 283 F    HW: 5Q0 919 283
       Component: PARKHILFE 4K  H10 0054
       Revision: --------    Serial number: 39291534203226
       Coding: 0000050011
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_EPHVA14AU3700000 002024
       ROD: EV_EPHVA14AU3700000_AU37.rod
       VCID: 3C771ADBB71F63DCB3-8068

    No fault code found.

    -------------------------------------------------------------------------------
    Address 15: Airbags (J234)       Labels: 5Q0-959-655.clb
       Part No SW: 5Q0 959 655 AB    HW: 5Q0 959 655 AB
       Component: AirbagVW20    015 0388
       Serial number: 003MMR1BC5J-
       Coding: 98CCC000000000005C540000004800000065
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_AirbaVW20SMEVW37X 002130
       ROD: EV_AirbaVW20SMEVW37X_VW37.rod
       VCID: 000FAE2B9B77C73CAF-8054

       Side Sensor Driver Front:
       Subsystem 1 - Part No SW: -----------    HW: 480 001 812 15
       Component: SideSensor_Df  001 0887
       Serial number: 357670000001F741381P
       Coding: 2D2D2D

       Side Sensor Passenger Front:
       Subsystem 2 - Part No SW: -----------    HW: 480 001 812 15
       Component: SideSensor_Pf  001 0887
       Serial number: 358670000007A741381R
       Coding: 2D2D2D

       Side Sensor Driver Rear:
       Subsystem 3 - Part No SW: -----------    HW: 480 402 811 15
       Component: SideSensor_Dr  001 6149
       Serial number: 3516502B11E34435E21%
       Coding: 2D2D2D

       Side Sensor Passenger Rear:
       Subsystem 4 - Part No SW: -----------    HW: 480 403 011 15
       Component: SideSensor_Pr  001 6149
       Serial number: 3526502C91E2431261B3
       Coding: 2D2D2D

       Front Sensor Driver:
       Subsystem 5 - Part No SW: -----------    HW: 480 401 509 15
       Component: FrontSensor_D  001 6149
       Serial number: 3556502C71CF2D82920N
       Coding: 2D2D2D

    No fault code found.

    -------------------------------------------------------------------------------
    Address 16: Steering wheel (J527)       Labels: 5Q0-953-549.clb
       Part No SW: 8V0 953 521 EM    HW: 5Q0 953 549 E
       Component: Lenks. Modul  003 0120
       Revision: --------    Serial number: 10121504221033
       Coding: 8018
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_SMLSKLOMQB 020001
       ROD: EV_SMLSKLOMQB_AU37.rod
       VCID: 0919B30FA84D8674F8-805C

    No fault code found.

    -------------------------------------------------------------------------------
    Address 17: Instruments (J285)       Labels: 5G0-920-XXX-17.clb
       Part No SW: 8V0 920 860 N    HW: 8V0 920 860 N
       Component: KOMBI         H03 6423
       Coding: 07851A082B8000080500BA001000000000000000
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_DashBoardVDDMQBAB 009051
       ROD: EV_DashBoardVDDMQBAB_AU37.rod
       VCID: 45817F3FC4D52214DC-8010

    No fault code found.

    -------------------------------------------------------------------------------
    Address 19: CAN Gateway (J533)       Labels: 5Q0-907-530-V1.clb
       Part No SW: 5Q0 907 530 AJ    HW: 5Q0 907 530 M
       Component: GW MQB High   212 2246
       Revision: --------    Serial number: 10121510800534
       Coding: 01010008300864005B000208100B00000001010000000000000000000000
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_GatewConti 013020
       ROD: EV_GatewConti.rod
       VCID: 79F9C3CFF8AD96F4E8-802C

       Generator:

       Multifunction unit control module:
       Subsystem 2 - Part No SW: 8U0 951 528     HW: 8U0 951 528
       Component: E221 - MFL  H02 0014
       Serial number: 11 12 2015  A0038721

    No fault code found.

    -------------------------------------------------------------------------------
    Address 42: Door Elect, Driver (J386)       Labels: 5QX-959-X93-42.clb
       Part No SW: 5Q0 959 393 E    HW: 5Q0 959 393 B
       Component: TSG FS        020 0041
       Serial number: 181015BJH00562
       Coding: 00100A204100040000001002
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_DCUDriveSideEWMINKLO 006003
       ROD: EV_DCUDriveSideEWMAXCONT.rod
       VCID: 41896B2FD0FD0E34E0-8014

       Subsystem 1 - Part No SW: 5Q0 959 811     HW: 5Q0 959 811
       Component: FOND_FHSG_DRV  005 0005
       Serial number: 00000000000008171337
       Coding: 110000

    No fault code found.

    -------------------------------------------------------------------------------
    Address 44: Steering Assist (J500)       Labels: 5Q0-909-144.clb
       Part No SW: 5Q0 909 144 S    HW: 5Q0 909 144 R
       Component: EPS_MQB_ZFLS  126 1063
       Coding: 0502
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_SteerAssisMQB 012140
       ROD: EV_SteerAssisMQB_VW37.rod
       VCID: 4487623BCFEF1B1CCB-8010

    No fault code found.

    -------------------------------------------------------------------------------
    Address 52: Door Elect, Pass. (J387)       Labels: 5QX-959-X92-52.clb
       Part No SW: 5Q0 959 392 E    HW: 5Q0 959 392 B
       Component: TSG BFS       020 0041
       Serial number: 111015BJA06371
       Coding: 001002204D00040000001002
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_DCUPasseSideEWMINKLO 006003
       ROD: EV_DCUPasseSideEWMAXCONT.rod
       VCID: 408F6E2BDBF7073CEF-8014

       Subsystem 1 - Part No SW: 5Q0 959 812     HW: 5Q0 959 812
       Component: FOND_FHSG_PSG  005 0005
       Serial number: 00000000000008176200
       Coding: 090000

    No fault code found.

    -------------------------------------------------------------------------------
    Address 55: Headlight Range (J431)       Labels: 5Q0-907-357.clb
       Part No SW: 5Q0 907 357     HW: 6R0 907 357 A
       Component: LWR-ECU       005 0080
       Revision: --------    Serial number: --------------
       Coding: 010A000001000000
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_HeadlRegulVWLWRMQB 001110
       ROD: EV_HeadlRegulVWLWRMQB_AU37.rod
       VCID: 75E1CFFFD4B5F2948C-8020

    No fault code found.

    -------------------------------------------------------------------------------
    Address 5F: Information Electr. (J794)       Labels: None
       Part No SW: 8V0 035 840 C    HW: 8V0 035 840 B
       Component: MU-S--ER      042 0461
       Serial number: A3E01212150142
       Coding: 01730100FF0A000021220001001A00002F0001040100010002
       Shop #: WSC 06385 790 00016
       ASAM Dataset: EV_MUStd6C3PASE 002020
       ROD: EV_MUStd6C3PASE_AU37.rod
       VCID: 35610FFF9435B2944C-8060

       Seat Adjustment Driver Side:
       Subsystem 1 - Part No SW: 8V0 919 603 C    HW: 8V0 919 603 C
       Component: DU Std  H49 0014
       Serial number: AUZ8Z9FY30F2K3

       Sound System:
       Subsystem 2 - Part No SW: 8V0 919 614 P    HW: 8V0 919 614 P
       Component: ControlUnit_B  H41 0054
       Serial number: ALJAL111111500010126

    No fault code found.

    End-------------------------(Elapsed Time: 03:40)--------------------------

  16. Likes Uwe, ineedbeer liked this post

Posting Permissions

  • You may not post new threads
  • You may not post replies
  • You may not post attachments
  • You may not edit your posts
  •
