    Controller refused to send a seed! Error : Unknown (0x00)

    I am using VCDs for 12 years now but never had this issue. I have 2 cars a 2019 A3 8V and a Audi Q2 with the same problems. I will post the autoscan from the Q2. The problem is as follows. I can do a full autoscan with no problems. And coding the gateway is no problem also but when trying to get in every other module will give the error: Controller refused to send a seed! Error : Unknown (0x00). Tryed a lot off things also tryed VCP but this gave the same issue. How can i solves this problem or what is the reason this error acure?



    Code:
    Tuesday,16,April,2019,18:32:57:27059
    VCDS -- Windows Based VAG/VAS Emulator Running on Windows 10 x64
    VCDS Version: 18.9.1.0 (x64)  HEX-NET CB: 0.4436.4
    Data version: 20190114 DS296.0
    www.Ross-Tech.com

    Dealer/Shop Name: Tunincenter Lowering

    VIN: WAUZZZGAXKA050866   License Plate: XX560P
    Mileage: 793km-492mi   Repair Order:



    --------------------------------------------------------------------------------
    --------------------------------------------------------------------------------


    Chassis Type: GA-AU37 (3Q0)
    Scan: 01 02 03 08 09 10 13 15 17 19 29 39 42 44 4B 52 5F BB BC D6
              D7

    VIN: WAUZZZGAXKA050866   Mileage: 793km-492miles

    01-Engine -- Status: Malfunction 0010
    02-Auto Trans -- Status: OK 0000
    03-ABS Brakes -- Status: OK 0000
    08-Auto HVAC -- Status: OK 0000
    09-Cent. Elect. -- Status: OK 0000
    10-Park/Steer Assist -- Status: OK 0000
    13-Auto Dist. Reg -- Status: Malfunction 0010
    15-Airbags -- Status: OK 0000
    17-Instruments -- Status: Malfunction 0010
    19-CAN Gateway -- Status: Malfunction 0010
    29-Left Light -- Status: OK 0000
    39-Right Light -- Status: OK 0000
    42-Door Elect, Driver -- Status: OK 0000
    44-Steering Assist -- Status: OK 0000
    4B-Multifunc. Module -- Status: Malfunction 0010
    52-Door Elect, Pass. -- Status: OK 0000
    5F-Information Electr. -- Status: Malfunction 0010
    BB-Door Rear Drv -- Status: OK 0000
    BC-Door Rear Pass -- Status: OK 0000
    D6-Light Ctrl Left 2 -- Status: OK 0000
    D7-Light Ctrl Right 2 -- Status: OK 0000
    -------------------------------------------------------------------------------
    Address 01: Engine (J623-DADA)       Labels:. 04E-907-309-V1.clb
       Part No SW: 05E 906 018 R    HW: 05E 907 309
       Component: R4 1.5l TFS   H22 6090
       Revision: 81H22000
       Coding: 022500322324150820000000000000000000000000000000
       Shop #: WSC 06314 790 00021
       ASAM Dataset: EV_ECM15TFS01105E906018R 003002
       ROD: EV_ECM15TFS01105E906018R.rod
       VCID: 3424D10F9F52DCEA09-8060

    1 Fault Found:
    23765 - Control unit for information electronics 1
              U1054 00 [032] - No Communication
              [Information electronics control module 1No Communication]
              Intermittent - Not Confirmed - Tested Since Memory Clear
                 Freeze Frame:
                        Fault Status: 00000001
                        Fault Priority: 6
                        Fault Frequency: 1
                        Mileage: 522 km
                        Date: 2019.04.13
                        Time: 13:58:44

                        Engine speed: 1307.50 /min
                        Normed load value: 4.3 %
                        Vehicle speed: 24 km/h
                        Coolant temperature: 98 °C
                        Intake air temperature: 30 °C
                        Ambient air pressure: 1020 mbar
                        Voltage terminal 30: 13.360 V
                        Unlearning counter according OBD: 32
                        Outside air temperature: 13 °C
                        Absolute intake pressure: 34 kPa abs
                        Engine torque: 36.9 Nm
                        Fuel: tank fill level: 50.0 l
                        Oxygen sensor bank 1 sensor 1: specified value: 1.0000
                        Particulate filter: loading stage: 0
                        Overrun cut-off-Bits 0-7: 0

    Readiness: 0000 0000

    -------------------------------------------------------------------------------
    Address 02: Auto Trans (J743)       Labels: None
       Part No SW: 0CW 300 043 D    HW: 0AM 927 769 E
       Component: GSG DQ200G2_M H05 1607
       Revision: 00005008    Serial number: CU501902205272
       Coding: 0014
       Shop #: WSC 17734 418 534600
       ASAM Dataset: EV_TCMDQ200021 001001
       ROD: EV_TCMDQ200021_VW31.rod
       VCID: 383CE53F833A388A25-806C

    No fault code found.

    -------------------------------------------------------------------------------
    Address 03: ABS Brakes (J104)       Labels: None
       Part No SW: 5Q0 614 517 EE    HW: 5Q0 614 517 BN
       Component: ESC           H35 0107
       Revision: 00000000    Serial number: 53548000005226
       Coding: 34006A8D2025246C8B7F0E0662C9242C560424D1704624F31221F074921B4A0300000633D2D21212FF35351919323200
       Shop #: WSC 06314 790 00021
       ASAM Dataset: EV_Brake1UDSContiMK100IPB 038007
       ROD: EV_Brake1UDSContiMK100IPB_038_AU37.rod
       VCID: 78BC253FC3BAF88AE5-802C

    No fault code found.

    -------------------------------------------------------------------------------
    Address 08: Auto HVAC (E87)       Labels:| 8V0-820-043.clb
       Part No SW: 8V0 820 043 AA    HW: 8V0 820 043 AA
       Component: AC Automat    H03 0140
       Revision: 20001000    Serial number: 00000001760141
       Coding: 06000004000000001000000000001000
       Shop #: WSC 06314 790 00021
       ASAM Dataset: EV_AirCondiFrontVaAU37X 008022
       ROD: EV_AirCondiFrontVaAU37X.rod
       VCID: 71AA181BA0C0A9C222-8024

       Relative humidity sensor in fresh air intake duct:
       Subsystem 1 - Part No SW: 4H0 907 658 B    HW: 4H0 907 658 B
       Component: AQ_Hum_Sensor  H02 0007
       Serial number: 96D2D29900PAG0MUFU03

    No fault code found.

    -------------------------------------------------------------------------------
    Address 09: Cent. Elect. (J519)       Labels: None
       Part No SW: 5Q0 937 084 DC    HW: 5Q0 937 084 CF
       Component: BCM MQBAB M+  H38 0273
       Serial number: 00001905801365
       Coding: 000000000000000000000000000000000000000000000000000000000000
       Shop #: WSC 06314 790 00021
       ASAM Dataset: EV_BCMMQB 019001
       ROD: EV_BCMBOSCH_019_VW37.rod
       VCID: 7CB4392FF782D4AA81-8028

       Rain Light Recognition Sensor:
       Subsystem 1 - Part No SW: 81A 955 555 A    HW: 81A 955 555
       Component: G397_RLFSS  H06 0002
       Serial number: 22540563X81A955555A0
       Coding: 80005E

       Light switch:
       Subsystem 2 - Part No SW: 8V0 941 531 AR    HW: 8V0 941 531 AR
       Component: E1 - LDS MQB  H06 0032
       Serial number: 05 12 2018  20001159

       Steering Column Switch:
       Subsystem 3 - Part No SW: 82A 953 521 B    HW: 5Q1 953 549
       Component: J527 SMLS MQB  004 0060
       Serial number: 00000015021904400014

    No fault code found.

    -------------------------------------------------------------------------------
    Address 10: Park/Steer Assist (J446)       Labels:| 5Q0-919-283.clb
       Part No SW: 5QA 919 283 C    HW: 5QA 919 283
       Component: PDC 4 KanalH07 0050
       Serial number: 000308419619055
       Coding: 0600040011
       Shop #: WSC 06314 790 00021
       ASAM Dataset: EV_EPHVA14AU3700000 009037
       ROD: EV_EPHVA14AU3700000.rod
       VCID: 4AD8AFF7EDD6BA1A43-801E

    No fault code found.

    -------------------------------------------------------------------------------
    Address 13: Auto Dist. Reg (J428)       Labels:| 2Q0-907-572.clb
       Part No SW: 2Q0 907 572 Q    HW: 2Q0 907 572 B
       Component: ACCCONTIMQB   H03 0342
       Coding: 3200000150F78728747C61450040A700000000000000000008
       Shop #: WSC 06314 790 00021
       ASAM Dataset: EV_ACCMRRCONTIVW376 003015
       ROD: EV_ACCMRRCONTIVW376.rod
       VCID: 42C887D7D5E6625A8B-8016

    3 Faults Found:
    1127 - Databus
              U1121 00 [008] - Missing Message
              [FAULT_TIMEOUT_PSD_04]
              Intermittent - Confirmed - Tested Since Memory Clear
                 Freeze Frame:
                        Fault Status: 00000001
                        Fault Priority: 6
                        Fault Frequency: 1
                        Reset counter: 55
                        Mileage: 522 km
                        Date: 2019.04.13
                        Time: 13:58:45

                        Voltage terminal 15: 13.3 V
                        Control Module temperature: 29 °C
                        Velocity_vehicle_reference: 6.92 m/s
                        Longitudinal_acceleration_vehicle_reference: 0.09 m/s²
                        Status_ACC_System: ACC_reversible_error

    1218 - Databus
              U1121 00 [008] - Missing Message
              [FAULT_TIMEOUT_PSD_05]
              Intermittent - Confirmed - Tested Since Memory Clear
                 Freeze Frame:
                        Fault Status: 00000001
                        Fault Priority: 6
                        Fault Frequency: 1
                        Reset counter: 55
                        Mileage: 522 km
                        Date: 2019.04.13
                        Time: 13:58:45

                        Voltage terminal 15: 13.4 V
                        Control Module temperature: 29 °C
                        Velocity_vehicle_reference: 6.93 m/s
                        Longitudinal_acceleration_vehicle_reference: 0.06 m/s²
                        Status_ACC_System: ACC_reversible_error

    1219 - Databus
              U1121 00 [008] - Missing Message
              [FAULT_TIMEOUT_PSD_06]
              Intermittent - Confirmed - Tested Since Memory Clear
                 Freeze Frame:
                        Fault Status: 00000001
                        Fault Priority: 6
                        Fault Frequency: 1
                        Reset counter: 55
                        Mileage: 522 km
                        Date: 2019.04.13
                        Time: 13:58:45

                        Voltage terminal 15: 13.4 V
                        Control Module temperature: 29 °C
                        Velocity_vehicle_reference: 6.93 m/s
                        Longitudinal_acceleration_vehicle_reference: 0.09 m/s²
                        Status_ACC_System: ACC_reversible_error


    -------------------------------------------------------------------------------
    Address 15: Airbags (J234)       Labels:| 5Q0-959-655.clb
       Part No SW: 5Q0 959 655 BN    HW: 5Q0 959 655 BN
       Component: AirbagVW21    007 0403
       Serial number: 003FHR529BCF
       Coding: 88CCF0C000000000585400DFC048000000C5
       Shop #: WSC 06314 790 00021
       ASAM Dataset: EV_AirbaVW20SMEVW37X 002164
       ROD: EV_AirbaVW20SMEVW37X.rod
       VCID: 0D5264EBDC38ED22A6-8058

       Side Sensor Driver Front:
       Subsystem 1 - Part No SW: -----------    HW: 480 002 602 19
       Component: SideSensor_Df  001 0887
       Serial number: 357000000005D475A93S
       Coding: 2D2D2D

       Side Sensor Passenger Front:
       Subsystem 2 - Part No SW: -----------    HW: 480 002 602 19
       Component: SideSensor_Pf  001 0887
       Serial number: 35800000000FD475A93$
       Coding: 2D2D2D

       Side Sensor Driver Rear:
       Subsystem 3 - Part No SW: -----------    HW: 480 402 202 19
       Component: SideSensor_Dr  003 6149
       Serial number: 3510001C52E4B1B3821+
       Coding: 2D2D2D

       Side Sensor Passenger Rear:
       Subsystem 4 - Part No SW: -----------    HW: 480 402 202 19
       Component: SideSensor_Pr  003 6149
       Serial number: 3520001C52E4B1B282DA
       Coding: 2D2D2D

       Front Sensor Driver:
       Subsystem 5 - Part No SW: -----------    HW: 480 400 702 19
       Component: FrontSensor_D  004 6149
       Serial number: 3550001022C0098283FW
       Coding: 2D2D2D

       Front Sensor Passenger:
       Subsystem 6 - Part No SW: -----------    HW: 480 400 702 19
       Component: FrontSensor_P  004 6149
       Serial number: 3560001022C0098285CW
       Coding: 2D2D2D

    No fault code found.

    -------------------------------------------------------------------------------
    Address 17: Instruments (J285)       Labels:| 5G0-920-XXX-17.clb-SRI3
       Part No SW: 81A 920 750 D    HW: 81A 920 750 D
       Component: KOMBI         H21 2603
       Coding: 05A4220C2B8000080D80E8001000000000000000
       Shop #: WSC 06314 790 00021
       ASAM Dataset: EV_DashBoardVDDMQBAB 009068
       ROD: EV_DashBoardVDDMQBAB_009_VW37.rod
       VCID: 25023C4B2488B5628E-8070

    4 Faults Found:
    16777018 - Function Restricted due to Interrupted Communications
              U1110 00 [008] - -
              [BAP_Audio_0x31 keine Kommunikation]
              Intermittent - Confirmed - Tested Since Memory Clear
                 Freeze Frame:
                        Fault Status: 00000001
                        Fault Priority: 6
                        Fault Frequency: 1
                        Reset counter: 55
                        Mileage: 522 km
                        Date: 2019.04.13
                        Time: 13:58:48

    16777020 - Function Restricted due to Interrupted Communications
              U1110 00 [008] - -
              [BAP_TEL_0x28 keine Kommunikation]
              Intermittent - Confirmed - Tested Since Memory Clear
                 Freeze Frame:
                        Fault Status: 00000001
                        Fault Priority: 6
                        Fault Frequency: 1
                        Reset counter: 55
                        Mileage: 522 km
                        Date: 2019.04.13
                        Time: 13:58:48

    16777022 - Function Restricted due to Interrupted Communications
              U1110 00 [008] - -
              [BAP_NAV SD_0x32 keine Kommunikation]
              Intermittent - Confirmed - Tested Since Memory Clear
                 Freeze Frame:
                        Fault Status: 00000001
                        Fault Priority: 6
                        Fault Frequency: 1
                        Reset counter: 55
                        Mileage: 522 km
                        Date: 2019.04.13
                        Time: 13:58:48

    16777026 - Function Restricted due to Interrupted Communications
              U1110 00 [008] - -
              [BAP_MFL_Jokerfunktion_0x34 keine Kommunikation]
              Intermittent - Confirmed - Tested Since Memory Clear
                 Freeze Frame:
                        Fault Status: 00000001
                        Fault Priority: 6
                        Fault Frequency: 1
                        Reset counter: 55
                        Mileage: 522 km
                        Date: 2019.04.13
                        Time: 13:58:48


    -------------------------------------------------------------------------------
    Address 19: CAN Gateway (J533)       Labels:| 3Q0-907-530-V1.clb
       Part No SW: 3Q0 907 530 AA    HW: 3Q0 907 530 C
       Component: GW MQB High   442 4367
       Revision: --------    Serial number: 0009156350
       Coding: 030100043F0857005B00004A180B00000001010000000000000000000000
       Shop #: WSC 06314 790 00021
       ASAM Dataset: EV_GatewNF 013025
       ROD: EV_GatewNF_VW37.rod
       VCID: 6E900367B1FEB63A3F-803A

       Alternator:
       Component: 1-01-02-01-04

       Multi Function Steering Wheel Control Module:
       Subsystem 2 - Part No SW: 81A 951 523     HW: 81A 951 523
       Component: J453 MFL  H04 0004
       Serial number: 20190211165438 22161

       Battery Monitoring Control Module:
       Subsystem 3 - Part No SW: 5Q0 915 181 J    HW: 5Q0 915 181 J
       Component: J367-BDMConti  H03 1051
       Serial number: 75886003911901281B75

    1 Fault Found:
    66052 - Infotainment CAN Bus (SAE Bus E)
              U0065 00 [008] - Performance
              [Globaler Timeout CAN-Infotainment]
              Intermittent - Confirmed - Tested Since Memory Clear
                 Freeze Frame:
                        Fault Status: 00000001
                        Fault Priority: 2
                        Fault Frequency: 1
                        Reset counter: 55
                        Mileage: 522 km
                        Date: 2019.04.13
                        Time: 13:58:45

                        Supply voltage: Terminal 30: 13.2 V
                        Terminal 15: On


    -------------------------------------------------------------------------------
    Address 29: Left Light (J1018)       Labels: 8S0-907-397.clb
       Part No SW: 8S0 907 397 C    HW: 8S0 907 397 C
       Component: LCM_MQB       H07 0022
       Shop #: WSC 00000 000 00000
       ASAM Dataset: EV_LCMLeftCONTIAU426 001009
       ROD: EV_LCMLeftCONTIAU426_VW41.rod
       VCID: 41CA88DBD0E0794292-8014

    No fault code found.

    -------------------------------------------------------------------------------
    Address 39: Right Light (J1023)       Labels: 8S0-907-397.clb
       Part No SW: 8S0 907 397 C    HW: 8S0 907 397 C
       Component: LCM_MQB       H07 0022
       Shop #: WSC 00000 000 00000
       ASAM Dataset: EV_LCMRightCONTIAU426 001009
       ROD: EV_LCMLeftCONTIAU426_VW41.rod
       VCID: 41CA88DBD0E0794292-8014

    No fault code found.

    -------------------------------------------------------------------------------
    Address 42: Door Elect, Driver (J386)       Labels:| 5QX-959-X93-42.clb
       Part No SW: 5Q0 959 593 F    HW: 5Q0 959 593 F
       Component: TSG FS001 0287
       Serial number: YE007SBF1391D
       Coding: 00148B204000000000001002
       Shop #: WSC 06314 790 00021
       ASAM Dataset: EV_DCU2DriveSideMAXHKLO 001010
       ROD: EV_DCU2DriveSideMAXHCONT_VW37.rod
       VCID: 44C481CFCFF26C6AB9-8010

    No fault code found.

    -------------------------------------------------------------------------------
    Address 44: Steering Assist (J500)       Labels:| 5Q0-909-144.clb
       Part No SW: 3Q0 909 144 M    HW: 3Q0 909 144 L
       Component: EPS_MQB_ZFLS  507 5082
       Coding: 011F0000
       Shop #: WSC 06314 790 00021
       ASAM Dataset: EV_SteerAssisMQB 015157
       ROD: EV_SteerAssisMQB_015.rod
       VCID: 3C34F92FB70214AAC1-8068

    No fault code found.

    -------------------------------------------------------------------------------
    Address 4B: Multifunc. Module (J745)       Labels:* None
       Part No SW: 3Q0 907 338 C    HW: 3Q0 907 338 C
       Component: FCM MQB Low   002 0345
       Serial number: 16021910802851
       Coding: 000000050900116200102B03020000000000000000000000000000000000
       Shop #: WSC 06314 790 00021
       ASAM Dataset: EV_MultiModulContiVW48X 002006
       ROD: EV_MultiModulContiVW48X_002_VW37.rod
       VCID: 3522EC0B9428C5E23E-8060

    1 Fault Found:
    13705489 - Databus
              U1121 00 [008] - Missing Message
              [PSD_04 data bus missing message]
              Intermittent - Confirmed - Tested Since Memory Clear
                 Freeze Frame:
                        Fault Status: 00000001
                        Fault Priority: 6
                        Fault Frequency: 1
                        Reset counter: 55
                        Mileage: 522 km
                        Date: 2019.04.13
                        Time: 13:58:45


    -------------------------------------------------------------------------------
    Address 52: Door Elect, Pass. (J387)       Labels:* None
       Part No SW: 5Q0 959 392 F    HW: 5Q0 959 392 F
       Component: TSG BFS001 0287
       Serial number: YE007SBG07106
       Coding: 001483204000000000001002
       Shop #: WSC 06314 790 00021
       ASAM Dataset: EV_DCU2PasseSideMAXHKLO 001010
       ROD: EV_DCU2PasseSideMAXHCONT_VW37.rod
       VCID: 41CA88DBD0E0794292-8014

    No fault code found.

    -------------------------------------------------------------------------------
    Address 5F: Information Electr. (J794)       Labels:* None
       Part No SW: 81A 035 193 E    HW: 81A 035 193
       Component: MU-HS-LN-EU   050 0235
       Serial number:
       Coding: 01720601FF00000011110001000A00102F00364401F00100CE
       Shop #: WSC 06314 790 00021
       ASAM Dataset: EV_MUHigScl6C3DELP 001011
       ROD: EV_MUHigScl6C3DELP_AU37.rod
       VCID: 2404214F2FB24C6A99-8070

       Data medium:
       Subsystem 1 - Part No SW: V03 959 802 LD    HW: -----------
       Component: ECE 2019  --- 0038
       Serial number: --------------------

       Display unit 1 for multimedia system:
       Subsystem 2 - Part No SW: 81A 919 604 B    HW: 81A 919 604 B
       Component: DU Std AU216  H42 0100
       Serial number: INX00106121800020247

       Multimedia Operating Unit:
       Subsystem 3 - Part No SW: 81B 919 614 A    HW: 81B 919 614 A
       Component: ControlUnit_B  H20 0200
       Serial number: APVAK106121800010143

    1 Fault Found:
    0006 - Antenna Amplifier 2 for Radio
              B126E 13 [008] - Open Circuit
              Intermittent - Confirmed - Tested Since Memory Clear
                 Freeze Frame:
                        Fault Status: 00000001
                        Fault Priority: 6
                        Fault Frequency: 3
                        Reset counter: 44
                        Mileage: 166 km
                        Date: 2019.04.08
                        Time: 14:29:58

                        Voltage terminal 30: 14.8 V
                        Status of antenna 2 for radio-Antenna current: 0 mA
                        Status of antenna 2 for radio-Connection between radio and antenna amplifier: Open circuit
                        Status of antenna 2 for radio-Connection between antenna amplifier and antenna: Not available
                        Status of antenna 2 for radio-Reception level antenna 2: 27 dBµV


    -------------------------------------------------------------------------------
    Address BB: Door Rear Drv (J388)       Labels:* None
       Part No SW: 8W1 959 595 D    HW: 8W1 959 595 D
       Component: TSG HFS003 0189
       Serial number: YE007SBJ0762E
       Coding: 000083004000000000001002
       Shop #: WSC 06314 790 00021
       ASAM Dataset: EV_DCU2RearDriveMAXHKLO 001010
       ROD: EV_DCU2RearDriveMAXHCONT.rod
       VCID: 4ED0A3E711BE963A1F-801A

    No fault code found.

    -------------------------------------------------------------------------------
    Address BC: Door Rear Pass (J389)       Labels:* None
       Part No SW: 8W1 959 595 D    HW: 8W1 959 595 D
       Component: TSG HBFS003 0189
       Serial number: YE007SBJ07768
       Coding: 000083004000000000001002
       Shop #: WSC 06314 790 00021
       ASAM Dataset: EV_DCU2RearPasseMAXHKLO 001010
       ROD: EV_DCU2RearPasseMAXHCONT.rod
       VCID: 4ED0A3E711BE963A1F-801A

    No fault code found.

    -------------------------------------------------------------------------------
    Address D6: Light Ctrl Left 2 (A31)       Labels: 7PP-941-572.clb
       Part No SW: 7PP 941 572 AC    HW: 7PP 941 572 A
       Component: LED1L         H09 0008
       Shop #: WSC 00000 000 00000
       ASAM Dataset: EV_LEDModLeftMELCOAU736 001004
       ROD: EV_LEDModLeftMELCOAU736_VW37.rod
       VCID: 177E0683EEE417F20C-8042

    No fault code found.

    -------------------------------------------------------------------------------
    Address D7: Light Ctrl Right 2 (A27)       Labels: 7PP-941-572.clb
       Part No SW: 7PP 941 572 AC    HW: 7PP 941 572 A
       Component: LED1R         H09 0008
       Shop #: WSC 00000 000 00000
       ASAM Dataset: EV_LEDModRightMELCOAU736 001004
       ROD: EV_LEDModLeftMELCOAU736_VW37.rod
       VCID: 177E0683EEE417F20C-8042

    No fault code found.

    End----------(Elapsed Time: 01:22, VBatt start/end: 12.3V/12.3V)-----------

    --------------------------------------------------------------------------------
    --------------------------------------------------------------------------------

    Address 17,81A 920 750 D,recoded (Long Coding-exp),from,05A4220C2B8000080D80E8001000000000000000 ,to,05A5220C2B8000080D80E8001000000000000000,(0631 4/790/00021),
    Last edited by Uwe; 05-14-2019 at 07:06 PM. Reason: CODE tags

  2. #2
    Verified VCDS User golfi_vend's Avatar
    Join Date
    Apr 2014
    Location
    Võru, Estonia
    Posts
    1,924
    Post Thanks / Like
    Open the hood and try again.
    I am a VW Freak - Le WV Freaks OR Come visit me at my work with ODIS concerns - FORSS ODIS GeKo/FaZit access for VW/AUDI/Škoda
    The world is my oyster...

  3. Likes Santos, PetrolDave, Eric, Uwe, jyoung8607, _Val liked this post
  4. #3
    Benevolent Dictator Uwe's Avatar
    Join Date
    Jan 2014
    Location
    Earth
    Posts
    23,087
    Post Thanks / Like
    Blog Entries
    1
    Quote Originally Posted by Antera View Post
    what is the reason this error acure?
    Diagnostic Firewall:
    https://forums.ross-tech.com/showthread.php?15536
    https://forums.ross-tech.com/showthread.php?17734

    On cars where we know it exists, VCDS will warn you.

    -Uwe-
    The engineering problems are likely insurmountable. It would be like proposing to land a rocket booster section on a barge floating in the middle of the ocean.

Posting Permissions

  • You may not post new threads
  • You may not post replies
  • You may not post attachments
  • You may not edit your posts
  •
